32-Channel Digital EEG Machine with Video Monitoring
Buyer ratings
The MedPrax 32-channel digital video EEG system is a comprehensive neurological diagnostic workstation engineered for routine clinical electroencephalography, continuous epilepsy video monitoring, and brain function research.
Saved items are stored on this browser only.
Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | MedPrax |
| Electrical supply | 100V / 240V · 50Hz / 60HzOther voltage and frequency configurations are available on request. |
| Classification | EEG MachineDigital EEGVideo EEGNeurologyEpilepsy MonitoringBrain MappingPhotic Stimulator |
| Clinical Applications | |
| Supplies to | GlobalIndiaMiddle EastAfricaSoutheast AsiaEuropeNorth America |
| Detailed Specs | • Channel Configuration: 32 unipolar/bipolar EEG channels + optional 8 polygraph channels (ECG, EMG, EOG, Resp) • Sampling & ADC: 24-bit high-precision A/D conversion with sampling rates up to 2000 Hz per channel • Video Synchronization: Synchronized high-definition (1080p) pan-tilt-zoom (PTZ) infrared night-vision camera with audio recording • Photic Stimulator: Integrated flash frequency generator (0.5 to 30 Hz) with automated and manual trigger protocols • Brain Mapping: Real-time 2D/3D brain electrical activity topographic mapping (BEAM), power spectrum analysis, and amplitude integration • Software Features: Automatic spike-wave detection, seizure onset alerting, PSG sleep staging, and customizable montage re-referencing • Trolley Workstation: Complete medical-grade mobile cart with headbox arm, isolation transformer, PC, and dual 24-inch monitors |
Product Description
Key Features and Capabilities
Combines a low-noise 32-channel amplifier headbox, synchronized HD pan-tilt-zoom infrared video monitoring, an automated programmable LED flash photic stimulator, and flexible digital montage re-referencing.
Diagnostic Performance
Delivers real-time spectral power analysis, automatic epileptic sharp/spike-wave pattern detection, 3D color topographic brain surface mapping, and sleep architecture scoring.
Clinical Applications
Crucial for epilepsy classification, unexplained seizure localization, encephalopathy diagnosis, coma prognosis in neuro-ICUs, and pre-surgical brain mapping.
Technical Specifications
Features high common-mode rejection ratio (CMRR >110 dB), input impedance >100 MΩ, and optical isolation shielding patient connections from electrical interference.
Recommended Settings
Hospital neurology departments, dedicated epilepsy monitoring units (EMU), neuro-intensive care units, and sleep diagnostic centers.
Summary
A premier 32-channel video EEG platform delivering crystal-clear neurological tracing and synchronized clinical video correlation. Procured through MedPrax Market.
